TCA and V-H computer test for spiral bevel and hypoid gears.
Here is an example of DDS calculation of a spiral bevel gear set. DDS method was used for calculation of gear tooth surfaces and for contact pattern simulation. TCA and V-H test can be done on a PC befor manufacturing the gears so it saves time for tooth contact development.
Spiral bevel TSA software has been developed by Dr. Boris Zak and Dip. Eng. Stepan Lunin.|
|
Nominal location. The upper picture shows the summary of the contact.
The picture in the middle shows the animation of the contact pass.
The lower picture shows transmission error. |
|
|
V=+0.1 Pinion has moved up for 0.1 mm. |
|
|
V=-0.1 Pinion has moved down for 0.1 mm. |
|
|
H=+0.1 Pinion has moved forward for 0.1 mm |
|
|
H=-0.1 Pinion has moved back for 0.1 mm. |
